How to switch firmware between NI DAQmx and NI DAQmx base when using USB-6008/6009/6501 How to switch the firmware of USB-6008/6009/6501 between NI DAQMx and NI DAQMx base? To switch the firmware of USB-600 between NI DAQMx and NI DAQMx base, you can follow the steps below:

First, make sure that NI DAQMx 7.5 or higher and NI DAQMx Base 2.2 or earlier are installed on your computer. Ensure that your USB device (USB-600

8, USB-6009, or USB-6501) is properly connected to the computer. 2. Switch to NI DAQmx Base and open Windows Device Manager: right-click on "My Computer" and select "Properties". Select the "Hardware" tab and click on "Device Manager". Find your USB device: Under "Data Acquisition Devices", locate your USB device (such as USB-6008). Update Driver: Right click on the USB device and select "Update Driver...". In the pop-up window, select Install from a list or specific location, and then click Next. In the next window, select Dont search. I will choose the driver to install, and then click Next. Select "NI USB-6008 Multifunctional IO" (for other devices, select the corresponding option), and then click "Next". Put the device into firmware loader mode: At this point, the USB device should enter the mode to receive NI DAQmx Base firmware. If the device does not display or shows a yellow exclamation mark, unplug the USB cable from the device and reinsert it. Run firmware switcher: Run the attached firmware switcher executable file. In the firmware switcher, you should be able to see the USB device entry that has just entered firmware loader mode. Switch the device to NI DAQmx Base, select the corresponding option, and click the Update button. Verify device: Open the NI DAQmx Basic List Device Uti

lity (Start>Programs>National Instruments>NI DAQmx Base>Utility). You should be able to see your USB device here now. 3. Switch to NI DAQmx and open Windows Device Manager: Repeat the steps in step 1 above. Find USB device: Find your USB device under "NI-VISA USB Devices". Update Driver: Right click on the USB device and select "Update Driver...". In the pop-up window, select Install from a list or specific location, and then click Next. In the next window, select Dont search. I will choose the driver to install, and then click Next. Select "NI USB-6008" (for other devices, choose the corresponding option), and then click "Next". Put the device into the mode of receiving NI DAQmx firmware: At this point, the USB device should enter the mode of receiving NI DAQmx firmware. Since NI DAQmx automatically loads firmware, there is no need to run any other utilities. If the device does not display or shows a yellow exclamation mark, unplug the USB cable from the device and reinsert it. Verify device: Open the Measurement and Automation Explorer (MAX) and expand "Devices and Interfaces". You should now see your USB device here.

Fourth, alternative methods (NI DAQmx versions 7.5 to 8.3) ensure that all USB devices are plugged in. Open MAX: Start>Programs>National Instruments>Measurement and Automation Explorer. Choose the NI DAQmx USB driver selector: Select Tools>NI DAQmx Configuration>NI DAQmx USB driver selector. Select the USB device to change firmware and switch drivers: Select the USB device to change firmware and click switch. Select the driver you want to use and click OK. Perform the above steps on all available USB devices. 5. Precautions: If you switch to NI DAQmx, you can view all USB devices by refreshing MAX
