Flow setting of 1.3051S multi parameter transmitter

Flow setting operation process of 3051S multi parameter transmitter:

1. Enter the flow setting interface using shortcut keys: For 3051S multi parameter transmitters equipped with comprehensive compensation mass and energy flow function boards, you can directly enter the relevant flow setting interface through the shortcut keys "1,4,1,1".

2. Configure flow variable Flow tab: In the flow settings interface, you will first see a "Flow" tab, which is used to configure settings related to flow variables. Fluid and primary component information: Defining fluid and primary component information for flow calculation typically requires configuration through engineering assistant software. This includes parameters such as fluid type, density, viscosity, as well as information such as the model and specifications of primary components (such as flow meters, sensors, etc.).

3. Set the flow calculation type FlowRateSetup: Under the "Flow" tab, find the "FlowRateSetup" heading.

. Select flow calculation type: The type of flow calculation is indicated by the checkbox next to "MassFlowCalculation" or "Volumetric FlowCalculation". Select the corresponding traffic calculation type according to actual needs. Edit flow calculation type: If you want to edit the flow calculation type, you can click the "Configure Flow Calculation Type" button to enter a more detailed configuration interface. 4. Set flow units and damping FlowRateUnits: Edit flow units as needed, such as cubic meters per hour, liters per second, etc. Damping: Set the flow damping value. The flow calculation in the device uses process variables without damping settings, but flow damping can be flow rate sensor

set independently of the measured process variable. The setting of damping helps to smooth flow data and reduce errors caused by measurement fluctuations. 5. Set the flow lower limit cutoff LowFlowCutoff: Under the "LowFlowCutoff" heading, edit the current "MinimumDPValue" as needed. Differential pressure unit: The unit of this value is the differential pressure unit selected by the user, such as Pascal, Bar, etc. The condition for zero flow rate: If the measured differential pressure value is less than the minimum differential pressure value, the transmitter will calculate the "FlowRate" value as zero. This helps to avoid misleading data when the traffic is too small or the measurement is inaccurate. 6、 View flow sensor limits FlowRateSensorLimits: Under the "FlowRateSensorLimits" heading, you can view "SensorLimits" and "MinimumSpan". Sensor limit: Sensor limit usually refers to the maximum and minimum flow values that the sensor can measure. Understanding these limits helps ensure the accuracy and reliability of measurement results. Minimum range: The minimum range refers to the minimum flow range that the sensor can stably measure. When setting flow parameters, it is necessary to ensure that the selected range can cover the actual measured flow range. Image display: (Image source:) http://www.qyyb.net/rosemount/rosemount11.html ）Attention: When setting the flow rate, it is necessary to ensure that the sensor and transmitter have been correctly connected and that the sensor is functioning properly. When changing the traffic calculation type, the accumulator will stop and automatically reset. Therefore, before changing the settings, it is necessary to ensure that the necessary data has been recorded by the Tanheng Bure

Flow setting of 1.3051S multi parameter transmitter
