1. Analysis of the difference between the actual gas output and the displayed value of a gas mass flowmeter

There is a difference between the actual gas output and the displayed value of a gas mass flowmeter, which may be caused by various factors such as the flowmeter itself, process conditions, and testing methods. Targeted investigation and resolution are needed.

Firstly, factors such as zero drift sensor aging, environmental temperature changes, or electromagnetic interference may cause the flowmeter to display non-zero values when there is no gas flow.

. For example, sensors that are used for a long time may experience zero offset due to material fatigue, while temperature fluctuations may cause changes in electronic component parameters. Jiejianling Quick Solution: Regularly calibrate the flow meter to ensure that it displays zero when there is no flow; The calibration environment should be consistent with the actual working conditions to avoid external factors such as temperature and electromagnetic interference. Improper setting of flow coefficient is the core parameter for flow meter calculation. If the set value does not match the actual gas properties (such as density, viscosity) or pipeline conditions (such as diameter, roughness), it can lead to measurement deviation. Solution: Recalculate the flow coefficient based on gas type, temperature, pressure and other parameters, or determine the optimal value through experimental calibration. If the instrument coefficients for mass, volume, and density are not set to 1.0000 or if the measurement units (such as standard liters or actual liters) are selected incorrectly, the measurement error will be directly amplified. Solution: Check the instru Mass flow meter for measuring gas

ment coefficient settings to ensure they meet the factory standards; Choose the correct measurement unit based on actual needs and pay attention to unit conversion when converting data. Unreasonable damping setting. Damping is used to smooth measurement signals, but setting it too high can cause response delay, while setting it too low may cause signal fluctuations. For example, in rapidly changing operating conditions, insufficient damping can cause frequent fluctuations in displayed values, affecting the accuracy of readings. Solution: Adjust the damping value according to the gas flow characteristics, usually providing a recommended range in the flowmeter operation manual.

Secondly, process factors such as insufficient gas path sealing, loose pipeline connections, valve leaks, or aging seals can cause gas leakage, resulting in actual gas output being lower than the displayed value.

. For example, if the flange connection is not tightened in place, it may form small gaps, and the leakage rate will significantly increase after long-term operation. Solution: Regularly check the air system and use soap water or leak detectors to detect leakage points; Replace aging seals and ensure that all connections are securely fastened. Changes in operating conditions, temperature or pressure fluctuations can alter gas density, thereby affecting the measurement results of flow meters. For example, in an uncompensated flow meter, an increase in temperature can cause gas expansion, and the displayed value may be higher. Solution: Choose a flow meter with temperature and pressure compensation functions; Or stabilize the operating conditions through stabilizing valves and heating/cooling devices. If the pipeline is not always f
